3. Installation
Tighten the two screws at the deep end
of the left side temporarily by performing
steps to .
Tighten the two screws at the front on the
right side by performing steps and .
Align the upper hole of the fastener with
the screw hole of the main unit. Insert
the screw from the bottom and tighten it
lightly.
Insert the fastener into the installation
position from the front on the left side of
the main unit.
