OM SYSTEM OM-5 User Manual

Setting a focus position for PreMF
Select [PreMF]
for AF mode, and press the INFO button.
Press the shutter button halfway to focus.
Focus can be adjusted by rotating the focus ring.
Press the OK button.
The focus distance for the preset focus point can be set using [Preset MF distance] in CCustom
Menud (P. 273).
The camera also focuses at the preset distance:
when turned on and
when you exit the menus to the shooting display.
Manual Focus Adjustment
When [S‑AFJ], [C‑AFJ], [MF], [C‑AF+TRJ], [PreMF], or [RAFJ] is selected for AF
mode, focus can be adjusted manually during exposures or while pictures are being taken in
[Sequential Low] mode.
In mode B (bulb), manual focus adjustment can be performed according to the option selected
for [Bulb/Time Focusing] (P. 318).
122
Choosing a focus mode (AF Mode)
1.
2.
3.
-
-

OM SYSTEM OM-5 Specifications

General

Sensor Type	Live MOS
Effective Pixels	20.4MP
Image Processor	TruePic IX
Viewfinder Resolution	2.36 million dots
LCD Screen Size	3.0 inches
LCD Screen Resolution	1.04 million dots
Shutter Speed	1/8000 to 60 sec
Dimensions	125.3 x 85.2 x 49.7 mm
Weight	414 g (body only)
Connectivity	Wi-Fi, Bluetooth
Memory Card Slot	1 x SD/SDHC/SDXC (UHS-II compatible)
Sensor Size	17.3 x 13 mm (Micro Four Thirds)
ISO Sensitivity	ISO 200-25600 (expandable to ISO 64)
Autofocus Points	121 points
Viewfinder Type	Electronic
LCD Screen Type	Tilting Touchscreen
Video Recording	4K UHD at 30p
Continuous Shooting	10 fps (mechanical shutter), 30 fps (electronic shutter)
Image Stabilization	5-axis sensor-shift
Weather Sealing	Yes
Battery Type	BLS-50 Lithium-Ion battery
Battery Life	Approx. 310 shots
Autofocus System	Contrast Detection AF
