OM SYSTEM OM-5 User Manual

Selected pictures are marked with a P. To deselect, pr
ess
the OK button again.
RAW RAW RAW
RAW
RAW RAW RAW
Image Overlay
Back
Set
Adjust the gain for each of the images in the overlay.
Highlight images using the HI buttons and adjust gain
using the FG buttons.
Gain can be adjusted in the range 0.1 – 2.0. Check the results
in the monitor.
×1.5×1.5×0.3 ×0.5
Image Overlay
Back
Set
Combining Pictures (Image Overlay)
Overlay existing RA
W photos to create a new picture. Up to 3 pictures can be included in the overlay.
The results can be modified by adjusting brightness (gain) separately for each picture.
Highlight [Edit] in the qPlayback Menu and press the OK button.
Highlight [Image Overlay] using the FG buttons and press the OK button.
Select the number of images to be overlaid and press the OK button.
Highlight RAW images for the overlay using FGHI and press the OK button.
An overlay will be displayed once the number of images selected in Step3 have been
selected.
Press the OK button; a confirmation dialog will be displayed.
Highlight [Yes] and press the OK button.
The overlay is saved in the format currently selected for image quality. Overlays created with [RAW]
selected for image quality are saved in RAW format and in JPEG format using the image quality
option selected for [X2]. gCCustom MenuG [X Set] (P. 288)
Overlays saved in RAW format can in turn be combined with other RAW images to create overlays
containing 4 or more pictures.
256
Combining Pictures (Image Overlay)
1.
2.
3.
4.
5.
6.
B
B

OM SYSTEM OM-5 Specifications

General

Sensor Type	Live MOS
Effective Pixels	20.4MP
Image Processor	TruePic IX
Viewfinder Resolution	2.36 million dots
LCD Screen Size	3.0 inches
LCD Screen Resolution	1.04 million dots
Shutter Speed	1/8000 to 60 sec
Dimensions	125.3 x 85.2 x 49.7 mm
Weight	414 g (body only)
Connectivity	Wi-Fi, Bluetooth
Memory Card Slot	1 x SD/SDHC/SDXC (UHS-II compatible)
Sensor Size	17.3 x 13 mm (Micro Four Thirds)
ISO Sensitivity	ISO 200-25600 (expandable to ISO 64)
Autofocus Points	121 points
Viewfinder Type	Electronic
LCD Screen Type	Tilting Touchscreen
Video Recording	4K UHD at 30p
Continuous Shooting	10 fps (mechanical shutter), 30 fps (electronic shutter)
Image Stabilization	5-axis sensor-shift
Weather Sealing	Yes
Battery Type	BLS-50 Lithium-Ion battery
Battery Life	Approx. 310 shots
Autofocus System	Contrast Detection AF
