OM SYSTEM OM-5 User Manual

Bluetooth Name
Bluetooth Passcode
Wi-Fi SSID
Wi-Fi Password
: xxxxxxxxxxx
: 000000
: xxx-x-x-xxxxxxxx
: 0000000000000000
3/3
Scan the QR code, using
the OI.Share app.
Connection Setup
Disconnect
ww
q
1
2
3
Bluetooth local name
Bluet
ooth P
asscode
Wi-Fi SSID
Wi-Fi Password
QR code
1
2
3
Pairing the Camera and Smartphone
Follow the steps below when connecting the devices for the fir
st time.
Adjust pairing settings using the OM Image Share app, not the settings app that is part of the
smartphone operating system.
Launch the copy of the dedicated OM Image Share app previously installed on your
smartphone.
Select [Device Connection] in the q Playback Menu and press I.
You can also connect by tapping e in the monitor.
Follow the on-screen guide to adjust Wi-Fi/Bluetooth settings.
The Bluetooth local name and passcode, the Wi-Fi SSID and password, and a QR code are
displayed in the monitor.
Tap the camera icon at the bottom of the OM Image Share display.
An [Easy Setup] tab will be displayed.
Follow the on-screen instructions in OM Image Share to scan the QR code and adjust
connection settings.
If you are unable to scan the QR code, follow the on-screen instructions in OM Image Share
to adjust settings manually.
Bluetooth: To connect, select the local name and enter the passcode displayed in the
camera monitor into the Bluetooth settings dialog OM Image Share.
Wi-Fi: To connect, enter the SSID and password displayed on the camera monitor into the
Wi-Fi settings dialog OM Image Share.
G1 will be displayed when pairing is complete.
The Bluetooth
®
icon indicates the status as follows:
p: The camera is emitting wireless signal.
q: Wireless connection has been established.
359
Pairing the Camera and Smartphone
1.
2.
3.
4.
5.
-
-
-
-

OM SYSTEM OM-5 Specifications

General

Sensor Type	Live MOS
Effective Pixels	20.4MP
Image Processor	TruePic IX
Viewfinder Resolution	2.36 million dots
LCD Screen Size	3.0 inches
LCD Screen Resolution	1.04 million dots
Shutter Speed	1/8000 to 60 sec
Dimensions	125.3 x 85.2 x 49.7 mm
Weight	414 g (body only)
Connectivity	Wi-Fi, Bluetooth
Memory Card Slot	1 x SD/SDHC/SDXC (UHS-II compatible)
Sensor Size	17.3 x 13 mm (Micro Four Thirds)
ISO Sensitivity	ISO 200-25600 (expandable to ISO 64)
Autofocus Points	121 points
Viewfinder Type	Electronic
LCD Screen Type	Tilting Touchscreen
Video Recording	4K UHD at 30p
Continuous Shooting	10 fps (mechanical shutter), 30 fps (electronic shutter)
Image Stabilization	5-axis sensor-shift
Weather Sealing	Yes
Battery Type	BLS-50 Lithium-Ion battery
Battery Life	Approx. 310 shots
Autofocus System	Contrast Detection AF
