OM SYSTEM OM-5 User Manual

Rotate the mode dial to P.
Focus and check the display.
Use the front and r
ear dials to adjust the following settings.
Front dial: Exposure compensation (P. 89)
Rear dial: Program shift (P. 50)
The shutter speed and aperture chosen by the camera are
displayed.
1023
1:02:03
P
S-IS AUTOS-IS AUTO
250 F5.6
0.0
30
p
30
p
4K
YFYF
ISO-A
200
1 2 3
Exposure mode
Shutter speed
Aperture
1
2
3
Letting the camera choose aperture and
shutt
er speed (
P: Program AE)
The camera chooses the optimal aperture and shutter speed according to subject brightness.
Exposure compensation can also be adjusted using the F button. Press the F button and
then rotate the front or rear dial.
Take pictures.
You can choose the functions performed by the front and rear dials. g “Assigning Roles to the
Front and Rear Dials (KDial Function)” (P. 319)
You can use the Fn lever to reverse the roles of the front and rear dials. The lever can also be
assigned other roles. g“Customizing the Fn Lever (KFn Lever Function)” (P. 321)
48
Letting the camera choose aperture and shutter
speed (P: Pr
ogram AE)
1.
2.
3.
B
B

OM SYSTEM OM-5 Specifications

General

Sensor Type	Live MOS
Effective Pixels	20.4MP
Image Processor	TruePic IX
Viewfinder Resolution	2.36 million dots
LCD Screen Size	3.0 inches
LCD Screen Resolution	1.04 million dots
Shutter Speed	1/8000 to 60 sec
Dimensions	125.3 x 85.2 x 49.7 mm
Weight	414 g (body only)
Connectivity	Wi-Fi, Bluetooth
Memory Card Slot	1 x SD/SDHC/SDXC (UHS-II compatible)
Sensor Size	17.3 x 13 mm (Micro Four Thirds)
ISO Sensitivity	ISO 200-25600 (expandable to ISO 64)
Autofocus Points	121 points
Viewfinder Type	Electronic
LCD Screen Type	Tilting Touchscreen
Video Recording	4K UHD at 30p
Continuous Shooting	10 fps (mechanical shutter), 30 fps (electronic shutter)
Image Stabilization	5-axis sensor-shift
Weather Sealing	Yes
Battery Type	BLS-50 Lithium-Ion battery
Battery Life	Approx. 310 shots
Autofocus System	Contrast Detection AF
