OM SYSTEM OM-5 User Manual

Flash control signals may interfere with exposure if the subject is too close to the camera. This can
be mitigated by r
educing the brightness of the camera flash, for example by using a diffuser.
Other external flash units
Note the following when using a third-party flash unit mounted on the camera hot shoe:
Using obsolete flash units that apply currents of more than about 250V to the X-contact will
damage the camera.
Connecting flash units with signal contacts that do not conform to our specifications may damage
the camera.
Select mode M, choose a shutter speed no faster than the flash sync speed, and set [KISO] to
[AUTO].
Flash control can only be performed by manually setting the flash to the ISO sensitivity and
aperture values selected with the camera. Flash brightness can be adjusted by adjusting either
ISO sensitivity or aperture.
Use a flash with an angle of illumination suited to the lens. Angle of illumination is usually expressed
using 35-mm format equivalent focal lengths.
437
Optional Accessories

OM SYSTEM OM-5 Specifications

General

Sensor Type	Live MOS
Effective Pixels	20.4MP
Image Processor	TruePic IX
Viewfinder Resolution	2.36 million dots
LCD Screen Size	3.0 inches
LCD Screen Resolution	1.04 million dots
Shutter Speed	1/8000 to 60 sec
Dimensions	125.3 x 85.2 x 49.7 mm
Weight	414 g (body only)
Connectivity	Wi-Fi, Bluetooth
Memory Card Slot	1 x SD/SDHC/SDXC (UHS-II compatible)
Sensor Size	17.3 x 13 mm (Micro Four Thirds)
ISO Sensitivity	ISO 200-25600 (expandable to ISO 64)
Autofocus Points	121 points
Viewfinder Type	Electronic
LCD Screen Type	Tilting Touchscreen
Video Recording	4K UHD at 30p
Continuous Shooting	10 fps (mechanical shutter), 30 fps (electronic shutter)
Image Stabilization	5-axis sensor-shift
Weather Sealing	Yes
Battery Type	BLS-50 Lithium-Ion battery
Battery Life	Approx. 310 shots
Autofocus System	Contrast Detection AF
