OM SYSTEM OM-5 User Manual

Highlight [AF Ar
ea]
using the FGHI buttons and press
the OK button.
AF Area
sRGB
Natural
S
Normal
WB
Auto
ISO
Auto
± 0
A ± 0
± 0 ± 0
± 0
G ± 0
P
250 F5.6
p
o
S - AF
Off
30
p
30
p
4K
S-IS Auto
Y
F
#
± 0.0
#
1023
1:02:03
M-IS
Positioning and Sizing the AF Target (AF Area)
Adjust AF-target settings. g“Choosing an AF T
arget Mode (AF Target Mode)” (P. 91), “Choosing a
Focus Target (AF Target Point)” (P. 95)
Press the OK button to display the LV super control panel.
AF-target selection options will be displayed.
Use the front or rear dial to choose an AF-target mode. You can position the target using the
FGHI buttons.
123
Positioning and Sizing the AF Target (AF Area)
1.
2.
3.

OM SYSTEM OM-5 Specifications

General

Sensor Type	Live MOS
Effective Pixels	20.4MP
Image Processor	TruePic IX
Viewfinder Resolution	2.36 million dots
LCD Screen Size	3.0 inches
LCD Screen Resolution	1.04 million dots
Shutter Speed	1/8000 to 60 sec
Dimensions	125.3 x 85.2 x 49.7 mm
Weight	414 g (body only)
Connectivity	Wi-Fi, Bluetooth
Memory Card Slot	1 x SD/SDHC/SDXC (UHS-II compatible)
Sensor Size	17.3 x 13 mm (Micro Four Thirds)
ISO Sensitivity	ISO 200-25600 (expandable to ISO 64)
Autofocus Points	121 points
Viewfinder Type	Electronic
LCD Screen Type	Tilting Touchscreen
Video Recording	4K UHD at 30p
Continuous Shooting	10 fps (mechanical shutter), 30 fps (electronic shutter)
Image Stabilization	5-axis sensor-shift
Weather Sealing	Yes
Battery Type	BLS-50 Lithium-Ion battery
Battery Life	Approx. 310 shots
Autofocus System	Contrast Detection AF
