The camera will switch to the keystone compensation
display. A slider and K icon will be display
ed.
P
250250 F5.6
Keystone correction and perspective control
(Keyst
one Comp.)
Keystone distortion due to the influence of lens focal length and proximity to the subject can be
corrected, or enhanced to exaggerate the effects of perspective. Keystone compensation can be
previewed in the monitor during shooting. The corrected image is created from a smaller crop, slightly
increasing the effective zoom ratio.
This option is available in P, A, S, M, and B modes.
Select [Keystone Comp.] in 7Shooting Menu2, and press the OK button.
Highlight [On], and press the OK button.
Press the MENU button to exit the menus.
Frame the shot and adjust keystone compensation while viewing your subject in the display.
Rotate the front dial to make horizontal adjustments and the rear dial to make vertical
adjustments.
Frame the shot and adjust keystone compensation while viewing your subject in the display.
Use the arrow pad (FGHI) to position the crop. The direction in which the crop can be
moved is shown by an arrow (J).
To cancel changes, press and hold the OK button.
To adjust aperture, shutter speed, and other shooting settings, press the INFO button.
The camera will exit to the shooting display.
A K icon is displayed while keystone compensation is enabled. The icon is displayed in
green if adjustments have been made to keystone compensation settings.
To return to the keystone compensation display shown in Step4, press the INFO button
repeatedly.
230
Keystone correction and perspective control
(K
eyst
one Comp.)
1.
2.
3.
4.
5.
