OM SYSTEM OM-5 User Manual

Combined Auto and Manual Focus
(KAF+MF)
MENU
Q C Q a Q [KAF+MF]
After focusing using autofocus, you can adjust focus manually by keeping the shutter button pressed
halfway and rotating the focus ring. Switch from auto to manual focus at will or fine-tune focus
manually after focusing with autofocus.
The procedure varies with the AF mode selected.
[Off] is selected by default.
On
Enable manual focus adjustment in autofocus mode. J displayed next t
o [S‑AF],
[C‑AF], [C‑AF+TR], or [R AF].
When [S‑AF J] is selected, you can keep the shutter button pressed halfway after
focusing using single AF and adjust focus manually. Alternatively, you can switch to
manual focus by rotating the focus ring while the camera is focusing. Focus can also
be adjusted manually while the shutter is open and during burst photography in
[Sequential Low] mode.
When [C‑AFJ] or [C‑AF+TRJ] is selected, you can switch to manual focus by
rotating the focus ring while the camera is focusing in continuous AF and continuous
tracking AF modes. Press the shutter button halfway a second time to refocus using
autofocus. Focus can also be adjusted manually while the shutter is open and during
burst photography in [Sequential Low] mode.
When [RAFJ] is selected, you can focus manually after focusing or before
initiating focus using R AF.
Off Manual focus adjustment disabled during autofocus.
Autofocus with manual focus is also available when autofocus is assigned to other camera controls.
gCCust
om Menu
a> [KAEL/AFL] (P. 299)
The lens focus ring can be used to interrupt autofocus only when M.ZUIKO PRO (Micro Four Thirds
PRO) lenses are used. For information on other lenses, visit our website.
In B (bulb) mode, manual focus is controlled by the option selected for [Bulb/Time Focusing].
298
Combined Auto and Manual Focus (KAF+MF)
B
B

OM SYSTEM OM-5 Specifications

General

Sensor Type	Live MOS
Effective Pixels	20.4MP
Image Processor	TruePic IX
Viewfinder Resolution	2.36 million dots
LCD Screen Size	3.0 inches
LCD Screen Resolution	1.04 million dots
Shutter Speed	1/8000 to 60 sec
Dimensions	125.3 x 85.2 x 49.7 mm
Weight	414 g (body only)
Connectivity	Wi-Fi, Bluetooth
Memory Card Slot	1 x SD/SDHC/SDXC (UHS-II compatible)
Sensor Size	17.3 x 13 mm (Micro Four Thirds)
ISO Sensitivity	ISO 200-25600 (expandable to ISO 64)
Autofocus Points	121 points
Viewfinder Type	Electronic
LCD Screen Type	Tilting Touchscreen
Video Recording	4K UHD at 30p
Continuous Shooting	10 fps (mechanical shutter), 30 fps (electronic shutter)
Image Stabilization	5-axis sensor-shift
Weather Sealing	Yes
Battery Type	BLS-50 Lithium-Ion battery
Battery Life	Approx. 310 shots
Autofocus System	Contrast Detection AF
