OM SYSTEM OM-5 User Manual

One-touch white balance
Measure whit
e balance by framing a piece of paper or other white object under the lighting that will
be used in the final photograph. Use this option to fine-tune white balance when you find it hard to
obtain the desired results with white balance compensation or preset white balance options such as
A (sunlight) or D (overcast). The camera stores the metered value for quick recall as required.
Select [J], [K], [L], or [M] (one-touch white balance 1, 2, 3, or 4).
Photograph a piece of colorless (white or gray) paper.
Frame the piece of paper so that it fills the display. Ensure that it is free of shadows.
In still photography mode, press the INFO button and then the shutter button.
In movie mode, press the INFO button to release the shutter.
The one-touch white balance screen appears.
Highlight [Yes] and press the OK button.
The new value is saved as a preset white balance option.
The new value is stored until one-touch white balance is measured again. Turning the power
off does not erase the data.
131
Adjusting color (WB (white balance))
1.
2.
3.

OM SYSTEM OM-5 Specifications

General

Sensor Type	Live MOS
Effective Pixels	20.4MP
Image Processor	TruePic IX
Viewfinder Resolution	2.36 million dots
LCD Screen Size	3.0 inches
LCD Screen Resolution	1.04 million dots
Shutter Speed	1/8000 to 60 sec
Dimensions	125.3 x 85.2 x 49.7 mm
Weight	414 g (body only)
Connectivity	Wi-Fi, Bluetooth
Memory Card Slot	1 x SD/SDHC/SDXC (UHS-II compatible)
Sensor Size	17.3 x 13 mm (Micro Four Thirds)
ISO Sensitivity	ISO 200-25600 (expandable to ISO 64)
Autofocus Points	121 points
Viewfinder Type	Electronic
LCD Screen Type	Tilting Touchscreen
Video Recording	4K UHD at 30p
Continuous Shooting	10 fps (mechanical shutter), 30 fps (electronic shutter)
Image Stabilization	5-axis sensor-shift
Weather Sealing	Yes
Battery Type	BLS-50 Lithium-Ion battery
Battery Life	Approx. 310 shots
Autofocus System	Contrast Detection AF
