Page #431 background imageLoading...
Page #431 background image
1
2
3
4
Shutter button
Front dial
R
emoval knob
Connector cap
1
2
3
4
Before attaching the grip, remove the connector
cover (a
) from the bottom of the camera and the
connector cap (b) from the ECG-5. Once attached,
make sure the ECG-5 removal knob is tightly
secured. Be sure to attach the connector cover to
the camera and the connector cap to the ECG-5
when the ECG-5 is not in use.
a
a
b
Store the connector cover (a) in the ECG-5
Optional Accessor
ies
Grip (EC
G-5)
The grip helps you keep the camera steady when using large lenses.
Make sure to turn the camera off when attaching and removing the grip.
Part names
Attaching the Grip
Main Specifications (ECG-5)
Dimensions
Approx. 128.4mm (W)× 76mm (H)× 60.2mm (D) (5.1″× 3.0″× 
2.4″) (excluding pr
otrusions)
Weight Approx. 121g (4.3oz.) (excluding terminal cap)
Splash resistance (when
attached to camera)
Type: Equivalent to IEC Standard publication 60529 IPX1
431
Optional Accessories
