OM SYSTEM OM-5 User Manual

Rotate the mode dial to B.
Select [LIVE COMP].
A
t default settings, the selection is made
with the rear dial.
1023
1:02:03
B
LIVE COMP
–0.3
F5.6
Press shutter button once
to prepare for composite
shooting.
1
Live composite
photography
1
Press the MENU button.
The
[Composite Settings] menu will be displayed.
Composite Settings
1sec
Exposure time per image.
Exposure time and
aperture
will determine your base exposure.
Back
Set
Lighten Blending (B: Live Composit
e
Photography)
Leave the shutter open for a long exposure. You can view the light trails left by fireworks or stars and
photograph them without changing the exposure of the background. The camera combines multiple
shots and records them as a single photograph.
We recommend that the camera be securely fixed to a tripod for live composite photography.
Highlight an exposure time using FG.
Choose an exposure time of from 1/2 to 60s.
Press the OK button to select the highlighted option.
The menus will be displayed.
62
Lighten Blending (B: Liv
e Composit
e
Photography)
C
1.
2.
3.
4.
5.

OM SYSTEM OM-5 Specifications

General

Sensor Type	Live MOS
Effective Pixels	20.4MP
Image Processor	TruePic IX
Viewfinder Resolution	2.36 million dots
LCD Screen Size	3.0 inches
LCD Screen Resolution	1.04 million dots
Shutter Speed	1/8000 to 60 sec
Dimensions	125.3 x 85.2 x 49.7 mm
Weight	414 g (body only)
Connectivity	Wi-Fi, Bluetooth
Memory Card Slot	1 x SD/SDHC/SDXC (UHS-II compatible)
Sensor Size	17.3 x 13 mm (Micro Four Thirds)
ISO Sensitivity	ISO 200-25600 (expandable to ISO 64)
Autofocus Points	121 points
Viewfinder Type	Electronic
LCD Screen Type	Tilting Touchscreen
Video Recording	4K UHD at 30p
Continuous Shooting	10 fps (mechanical shutter), 30 fps (electronic shutter)
Image Stabilization	5-axis sensor-shift
Weather Sealing	Yes
Battery Type	BLS-50 Lithium-Ion battery
Battery Life	Approx. 310 shots
Autofocus System	Contrast Detection AF
