OM SYSTEM OM-5 User Manual

Highlight [Gradation] using the FGHI buttons.
Gradation
sRGB
WB
Auto
ISO
Auto
A ± 0
G ± 0
P
250 F5.6
p
Natural
S
Normal
± 0 ± 0
± 0
o
S - AF
Off
30
p
30
p
4K
S-IS Auto
Y
F
#
± 0.0
#
1023
1:02:03
M-IS
Making fine adjustments to tone (Gradation)
Adjust shading and color brightness. You can bright
en or darken the entire picture to bring it closer to
what you envisage. The difference in contrast can be adjusted to capture details in both shadows and
highlights. Settings are stored separately for each picture mode.
Press the OK button to display the LV super control panel.
Use the front dial to select an option.
D Auto
Shadow Adj
Divides the image int
o detailed regions and adjusts the
brightness separat
ely for each region. This is effective for
images with areas of large contrast in which the whites
appear too bright or the blacks appear too dark.
D Normal
Gradation
Normal
Optimal shading. Recommended in most circumstances.
D High
Gradation High
Key
Uses a tone suitable for a bright subject.
D Low
Gradation Low
Key
Uses a tone suitable for a dark subject.
161
Making fine adjustments to tone (Gradation)
1.
2.
3.

OM SYSTEM OM-5 Specifications

General

Sensor Type	Live MOS
Effective Pixels	20.4MP
Image Processor	TruePic IX
Viewfinder Resolution	2.36 million dots
LCD Screen Size	3.0 inches
LCD Screen Resolution	1.04 million dots
Shutter Speed	1/8000 to 60 sec
Dimensions	125.3 x 85.2 x 49.7 mm
Weight	414 g (body only)
Connectivity	Wi-Fi, Bluetooth
Memory Card Slot	1 x SD/SDHC/SDXC (UHS-II compatible)
Sensor Size	17.3 x 13 mm (Micro Four Thirds)
ISO Sensitivity	ISO 200-25600 (expandable to ISO 64)
Autofocus Points	121 points
Viewfinder Type	Electronic
LCD Screen Type	Tilting Touchscreen
Video Recording	4K UHD at 30p
Continuous Shooting	10 fps (mechanical shutter), 30 fps (electronic shutter)
Image Stabilization	5-axis sensor-shift
Weather Sealing	Yes
Battery Type	BLS-50 Lithium-Ion battery
Battery Life	Approx. 310 shots
Autofocus System	Contrast Detection AF
