Set the unit mounted on the camera to [TTL A
UTO].
Flash control settings for the FL‑LM3 can only be adjusted using the camera.
Positioning Remote Flash Units
Set the wireless RC flash units to RC mode.
After turning compatible flash units on, press the MODE button and choose RC mode.
Choose a group for each of the compatible flash units using flash controls and match the
channel to that selected with the camera.
Position the flash units.
Position the wireless units with the remote sensors facing the camera.
Take pictures after confirming that the remote units and the unit on the camera are charged.
Wireless Flash Control Range
The illustration is intended as a guide only. The flash control range varies with the type of flash
mounted on the camera and the conditions in the surrounding area.
Flash Control Range for Camera-Mounted FL-LM3 Flash Units
7m
5
m
100°100°
5
50°
5
50°
60°60°
3
30°
30°30°
We recommend that each group contain no more than 3 flash units.
Wireless flash photography is not available in anti-shock mode or in rear-curtain slow sync mode
when a shutter speed slower than 4s is selected.
Start wait times longer than 4s cannot be selected in anti-shock and silent modes.
436
Optional Accessories
5.
1.
2.
3.
