OM SYSTEM OM-5 User Manual

Choose the playback frame rate.
Highlight an option using the FG buttons.
Pr
ess the OK button to select the highlighted option and exit.
Focus, exposure, and white balance lock during recording.
Sound is not recorded.
The picture angle is slightly reduced.
Aperture, shutter speed, exposure compensation, and ISO sensitivity cannot be changed during
recording.
Time codes cannot be recorded or displayed.
Brightness may change if zoom is adjusted during recording.
Individual movie files recorded to SD or SDHC memory cards can be up to 4GB in size. With SDXC
cards, recording will end before the movie reaches a length with a playback time of 2 hours.
High-speed movie recording is not available while the camera is connected to an HDMI device.
[nImage Stabilizer]> [M-IS1] is not available.
[Movie A] cannot be used.
[i-Enhance], [e-Portrait], and art filter picture modes are not available.
[Gradation] is fixed at [Gradation Normal].
High-speed movie recording is not available during remote photography when the camera is
connected to a smartphone.
145
Frame Size, Rate, and Compression (nX)
3.
4.
C
C
C
C
C
C
C
C
C
C
C
C
C

OM SYSTEM OM-5 Specifications

General

Sensor Type	Live MOS
Effective Pixels	20.4MP
Image Processor	TruePic IX
Viewfinder Resolution	2.36 million dots
LCD Screen Size	3.0 inches
LCD Screen Resolution	1.04 million dots
Shutter Speed	1/8000 to 60 sec
Dimensions	125.3 x 85.2 x 49.7 mm
Weight	414 g (body only)
Connectivity	Wi-Fi, Bluetooth
Memory Card Slot	1 x SD/SDHC/SDXC (UHS-II compatible)
Sensor Size	17.3 x 13 mm (Micro Four Thirds)
ISO Sensitivity	ISO 200-25600 (expandable to ISO 64)
Autofocus Points	121 points
Viewfinder Type	Electronic
LCD Screen Type	Tilting Touchscreen
Video Recording	4K UHD at 30p
Continuous Shooting	10 fps (mechanical shutter), 30 fps (electronic shutter)
Image Stabilization	5-axis sensor-shift
Weather Sealing	Yes
Battery Type	BLS-50 Lithium-Ion battery
Battery Life	Approx. 310 shots
Autofocus System	Contrast Detection AF
