OM SYSTEM OM-5 User Manual

Time Code
Settings
Choose how time codes are recorded in movie mode.
Set [Time Code Mode] to
[Drop Frame] to record time codes corrected for
errors with respect to recording time, and to [Non-DF] (no drop frame) to
record uncorrected time codes.
Set [Count Up] to [Rec Run] to run time codes during recording only, and to
[Free Run] to run time codes even while recording is stopped, including when
the camera is turned off.
In [Starting Time], set a starting time for the time code. Set [Current Time]
to set the time code for the current frame to 00. To set to 00:00:00:00, select
[Reset]. You can also set time codes using [Manual Input].
aView Assist
The display can be adjusted for ease of viewing when a movie-only picture
mode option ([kFlat] or [lOM-Log400]) is selected. Select [On] to
adjust the display hues for ease of viewing.
Movie c
Select [Off] t
o disable audio recording during filming (P. 246).
nHDMI Output
Adjust output settings for movies recorded with the camera connected with an external device via
HDMI.
Output Mode
Choose the video output mode. When set to [Monit
or Mode], image and
camera infor
mation are output. The camera information is not displayed on the
camera screen.
When set to [Record Mode], only image is output. The camera information is
displayed on the camera screen.
Not available when [4K] or [C4K] is selected for [nSpecification
Setting]> [nX] (P. 141).
REC Bit
If set to [On], the REC trigger is sent fr
om the camera t
o the connected
external device.
Time Code
If set to [On], the time code is sent from the camera to the connected external
device.
External devices triggered by time codes may stop recording if:
the footage requires extensive processing, or
you switch between the monitor and viewfinder.
236
The Video Menu
C
C
-
-

OM SYSTEM OM-5 Specifications

General

Sensor Type	Live MOS
Effective Pixels	20.4MP
Image Processor	TruePic IX
Viewfinder Resolution	2.36 million dots
LCD Screen Size	3.0 inches
LCD Screen Resolution	1.04 million dots
Shutter Speed	1/8000 to 60 sec
Dimensions	125.3 x 85.2 x 49.7 mm
Weight	414 g (body only)
Connectivity	Wi-Fi, Bluetooth
Memory Card Slot	1 x SD/SDHC/SDXC (UHS-II compatible)
Sensor Size	17.3 x 13 mm (Micro Four Thirds)
ISO Sensitivity	ISO 200-25600 (expandable to ISO 64)
Autofocus Points	121 points
Viewfinder Type	Electronic
LCD Screen Type	Tilting Touchscreen
Video Recording	4K UHD at 30p
Continuous Shooting	10 fps (mechanical shutter), 30 fps (electronic shutter)
Image Stabilization	5-axis sensor-shift
Weather Sealing	Yes
Battery Type	BLS-50 Lithium-Ion battery
Battery Life	Approx. 310 shots
Autofocus System	Contrast Detection AF
