Omron F3SG series User Manual

223
F3SG-R
User’s Manual
Chapter7 Optional Accessories(Sold Separately)
Appendix
E
Interface Unit
Bluetooth
®
Communication Unit
Lamp and Bluetooth
®
Communication Unit
Lamp
End Cap
Appearance Model Remarks
F39-GIF A dedicated cable is also supplied.
Appearance Model Remarks
F39-BT Used for the receiver.
Appearance Model Remarks
F39-BTLP Used for the receiver.
Appearance Model Remarks
F39-LP Used for the receiver.
Appearance Model Remarks
F39-CNM Housing color: Black
For both F3SG-RA emitter and receiver
(Attached to the F3SG-RA. The End Cap can be purchased if lost. )

Omron F3SG series Specifications

General

Type	Safety Light Curtain
Protection Rating	IP67
Connection	M12 connector
Detection Method	Infrared Light
Operating Temperature	-10°C to +55°C
Resolution	14mm, 25mm, 40mm
Standards	EN/IEC 61496-1, EN ISO 13849-1
Power Supply Voltage	24V DC ±10%
