Custom Dialogs
107
3
Performing Test Measurement/Starting Operation
Vision System FH/FZ5 Series
User’s Manual (Z340)
Radio Button Setting Region
Check Box Setting Region
Combo Box Setting Region
Parameter Set value [Factory default] Description
Target unit No.
0 to Number of units in the
display target scene - 1
[0]
Specify the unit to be the target for the radio button setting.
The units that are registered for the scene that is the target
of the normal dialog box will appear in the combo box.
Select the processing unit to set.
Target data No.
0 to 9999999
[0]
Specify the data to be the target for the radio button setting.
Enter the data number for the unit that is specified by the
target unit number.
[Data reference] button ---
You can select the data number directly to enter it, or you
can enter it with the [Data reference] button.
Click the [Data reference] button to select the target data in
the [Data reference] dialog box.
Set value
0 to 9999999
[0]
Enter the numeric value to set in the target data when the
radio button is selected.
The numeric value that is set here is the set value for that
selected radio button that is applied to the data for the target
data number when the operator changes the radio button
selection on the actual custom dialog box.
Parameter Set value [Factory default] Description
Target unit No.
0 to Number of units in the
display target scene - 1
[0]
Specify the unit to be the target for the check box setting.
The units that are registered for the scene that is the target
of the normal dialog box will appear in the combo box.
Select the processing unit to set.
Target data No.
0 to 9999999
[0]
Specify the data to be the target for the check box setting.
Enter the data number for the unit that is specified by the
target unit number.
[Data reference] button ---
You can select the data number directly to enter it, or you
can enter it with the [Data reference] button.
Click the [Data reference] button to select the target data in
the [Data reference] dialog box.
Parameter Set value [Factory default] Description
Target unit No.
0 to Number of units in the
display target scene - 1
[0]
Specify the unit to be the target for the combo box setting.
The units that are registered for the scene that is the target
of the normal dialog box will appear in the combo box.
Select the processing unit to set.
Target data No.
0 to 9999999
[0]
Specify the data to be the target for the combo box setting.
Enter the data number for the unit that is specified by the
target unit number.
[Data reference] button ---
You can select the data number directly to enter it, or you
can enter it with the [Data reference] button.
Click the [Data reference] button to select the target data in
the [Data reference] dialog box.
