Custom Dialogs
106
Vision System FH/FZ5 Series
User’s Manual (Z340)
Limit Box Setting Region
Soft Keyboard Setting Region
Min value
−999999.9999 to
999999.9999
[−999999.9999]
Enter the minimum value that can be entered with the
numeric setting.
Parameter Set value [Factory default] Description
Target lower unit No.
0 to Number of units in the
display target scene - 1
[0]
Specify the unit to be the target for the upper/lower limit
setting.
The units that are registered for the scene that is the target
of the normal dialog box will appear in the combo box.
Select the processing unit to set. Set the same unit number
as the upper target unit number.
Target upper unit No.
Target upper unit No.
[0]
Specify the unit to be the target for the upper/lower limit
setting.
The units that are registered for the scene that is the target
of the normal dialog box will appear in the combo box.
Select the processing unit that you wish to set. Set the same
unit number as the lower target unit number.
Target data No.
0 to 9999999
[0]
Specify the data to be the target for the upper/lower limit
setting.
Enter the data number for the unit that is specified by the
target unit number.
[Data reference] button ---
You can select the data number directly to enter it, or you
can enter it with the [Data reference] button.
Click the [Data reference] button to select the target data in
the [Data reference] dialog box.
Decimal digits
0 to 4
[4]
Enter the number of digits after the decimal place that can
be entered by the upper/lower limit setting.
Max value
−999999.9999 to
999999.9999
[999999.9999]
Enter the maximum value that can be entered with the
upper/lower limit setting.
Min value
−999999.9999 to
999999.9999
[−999999.9999]
Enter the minimum value that can be entered with the upper/
lower limit setting.
Parameter Set value [Factory default] Description
Target unit No.
0 to Number of units in the
display target scene - 1
[0]
Specify the unit to be the target for the character string
setting.
The units that are registered for the scene that is the target
of the normal dialog box will appear in the combo box.
Select the processing unit to set.
Target data No. 0 to 9999999, [0]
Specify the data to be the target for the character string
setting.
Enter the data number for the unit that is specified by the
target unit number.
[Data reference] button ---
You can select the data number directly to enter it, or you
can enter it with the [Data reference] button.
Click the [Data reference] button to select the target data in
the [Data reference] dialog box.
Parameter Set value [Factory default] Description
