Basic Knowledge For Macro Customize Functions
178
Vision System FH/FZ5 Series
User’s Manual (Z340)
Procedure for Using the unit calculation macro processing item
The usage flow for the unit calculation macro processing item and the basic usage procedures are described
below.
Item name Step Description
Function registration
and preparation
Register a function and display the
setting screen
Register processing items that enable use of macro customize
functions in the measurement flow, and open tool screens.
The specific procedure depends on the each functions.
--- ↓ ---
Function settings
Default function settings
Prepare initial settings and variables.
The specific procedure depends on the each functions.
↓ ---
Creation of processing content Write the program.
↓ ---
Program debug
Check operation Check if your settings operate as expected.
↓ ---
Debug
Debug the program.
Debug helps you identify the cause of the unexpected operation
and correct the program to run as expected.
--- ↓ ---
Save Save settings Save your changes.
Item name Step Description
---
Registration of a unit calculation
macro processing unit
Add a macro calculation processing unit to the measurement
flow.
--- ↓ ---
Settings of the unit
calculation macro
processing unit
(Reference:
XDescription of the
Setting Screen for the
"Unit Calculation
Macro" Processing
Item and How to
Configure Settings
(p.186))
Selection of operators
Select the checkboxes of operators to be used in the unit
calculation macro.
↓ ---
Reference Variable Settings
Set reference values if reference values will be used.
Set reference values in order to use data other than that of
the macro calculation processing unit, such as external
reference data of other processing units and system data.
↓ ---
Program input Write the program.
↓ ---
Setting of judgement conditions Set the conditions used to judge calculation results.
↓ ---
Program debug
(Reference: XHow to
Use the Debug
Function (p.235))
Check operation Check if your settings operate as expected.
↓ ---
Debug
Debug the program.
Debug helps you identify the cause of the unexpected
operation and correct the program to make the unit
calculation macro processing unit operate as expected.
--- ↓ ---
--- Saving settings Save your changes.
