Basic Knowledge For Macro Customize
Functions
179
5
Optimizing Scenes (Measurement Flows) (Macro Customize
Functions)
Vision System FH/FZ5 Series
User’s Manual (Z340)
Procedure for Using the Scene Control Macro Tool
The usage flow for the scene control macro tool and the basic usage procedures are described below.
Procedure for Using the Communication Command Macro Tool
The usage flow for the communication command macro tool and the basic usage procedure are described below.
Item name Step Description
---
Starting the Scene Control Macro
Tool
Start the scene control macro tool from the external tools.
--- ↓ ---
Scene control macro
tool settings
(Reference:
XDescription of the
Setting Screen of the
Scene Control Macro
Tool and How to
Configure Settings
(p.190))
Reference Variable Settings
Set reference values if reference values will be used.
Set reference variables in order to use data such as external
reference data of processing units and system data.
↓ ---
Unit label settings
Set unit labels if unit labels will be used.
Make preparations to use unit labels, rather than processing
unit numbers, to reference processing units in the
measurement flow.
↓ ---
Program input Write in the program.
↓ ---
Program debug
(Reference: XHow to
Use the Debug
Function (p.235))
Check operation Check if your settings operate as expected.
↓ ---
Debug
Debug the program.
Debug helps you identify the cause of the unexpected
operation and correct the program to make the scene control
macro operate correctly.
--- ↓ ---
--- Saving settings Save your changes.
Item name Step Description
--- Starting the communication
command macro tool
Start the communication command macro tool from the
external tools.
--- ↓ ---
Communication
command macro
settings
(Reference:
XComponents of the
Setting Screen of the
Communication
Command Macro Tool
and How to Configure
Settings (p.192))
Selection of the communication
command macro to be used
Select the checkbox of the communication command macro
to be used.
↓ ---
Communication command macro
name setting
Assign a name to the communication command macro.
↓ ---
Flow signal output setting
Select whether flow signals such as the BUSY signal are
turned ON or left OFF during processing. To turn on, select
the checkbox.
↓ ---
Program input Write the program.
↓ ---
