Basic Knowledge For Macro Customize Functions
230
Vision System FH/FZ5 Series
User’s Manual (Z340)
The relation between sensor controller screen transitions and program execution timing is shown below.
Process Transitions and Execution Timing
The timing of macro customize program execution is related both to screen transitions and to the type of
process being executed.
The relation between process type and program execution timing is shown below.
Execution timing of subroutine
Pre-defined subroutine
name
Screen transition
Original screen New screen
Program initialization *MCRINIT
Splash screen Main screen
Properties screen
(macro customize
functions)
Flow edit screen
Main screen
Tool screen
(Macro customize
functions)
Main screen
Measurement initialization *MEASUREINIT
Splash screen
Flow edit screen
Menu screen
Tool screen
Properties screen
Main screen
Measurement execution *MEASUREPROC --- ---
View
Screen display *MEASUREDISPI --- ---
Text display *MEASUREDISPT --- ---
Graphic display *MEASUREDISPG --- ---
Measurement flow update *RENUMPROC --- ---
Measurement result clear *CLEARMEASUREDATA --- ---
Process
Timing of
execution
during process
Timing of
execution after
process
Description
Scene change ---
Measurement
initialization
Scene change process. The program is executed when
measurement initialization takes place after the process.
Measurement result
clear
Measurement
result clear
Measurement
initialization
Measurement result clear process. The program is
executed when the measurement result is cleared during
the process, and when measurement initialization takes
place after the process.
Measurement
execution
Measurement
execution
---
Measurement execution process. The program is executed
when measurement is executed during the process.
Image display ---
Image display process. The program is executed when the
image is displayed during the process.
Graphic display ---
Graphic display process. The program is executed when
graphic display takes place during the process.
Text display ---
Text display process. The program is executed when text
display takes place during the process.
Flow edit
Measurement
flow update
---
Measurement flow update process. The program is
executed when the flow is updated during the process.
Measurement flow update consists of the operation and
process by which the unit number of the measurement flow
is updated, including adding and deleting processing units
to the measurement flow and changing the order.
