Parallel Processing
289
7
Changing the System Environment
Vision System FH/FZ5 Series
User’s Manual (Z340)
Processing Items That Supports Automatic Parallelization
The following table lists the processing items that support the automatic parallelization.
Processing item
Parallel-
ize pro-
cessing
Processing item
Parallel-
ize pro-
cessing
Processing item
Parallel-
ize pro-
cessing
Camera Image Input --- Glue Bead Inspection OK Statistics ---
Camera Image Input FH --- Position Compensation --- Reference Calib Data ---
Camera Image Input HDR --- Filtering --- Position Data Calculation ---
Camera Image Input HDR Lite --- Back Ground Suppression --- Stage Data ---
Camera Switching --- Brightness Correct Filter --- Robot Data ---
Measurement Image
Switching
--- Color Gray Filter ---
Vision Master Calibration ---
Search OK Extract Color Filter ---
PLC Master Calibration ---
Flexible Search OK Anti-Color Shading --- Convert Position Data ---
Sensitive Search OK Stripes Removal Filter II --- Movement Single Position ---
ECM Search OK Polar Transformation --- Movement Multi Points ---
EC Circle Search OK Trapezoidal Correction --- Detection Point ---
Ec Corner OK Machine Simulator --- Camera Calibration ---
Ec Cross OK Image Subtraction --- Data Save ---
Shape Search II OK Advanced Filter --- Conditional Branch ---
Classification OK Panorama --- End ---
Edge Position OK Calculation --- DI Branch ---
Edge Pitch OK Line Regression --- Control Flow Normal ---
Scan Edge Position OK Circle Regression --- Control Flow PLC Link ---
Scan Edge Width OK Precise Calibration --- Control Flow Parallel ---
Circular Scan Edge Position OK User Data --- Control Flow Fieldbus ---
Circular Scan Edge Width OK Set Unit Data --- Selective Branch ---
Color Data OK Get Unit Data --- Data Output ---
Gravity and Area OK Set Unit Figure --- Parallel Data Output ---
Labeling OK Get Unit Figure --- Parallel Judgement Output ---
Label Data --- Trend Monitor --- Fieldbus Data Output ---
Defect OK Image Logging --- Result Display ---
Precise Defect OK Image Conversion Logging --- Display Image File ---
Fine Matching OK Data Logging --- Display Last NG Image ---
Character Inspection OK Elapsed Time --- OCR OK
Date Verification --- Wait --- OCR User Dictionary ---
Model Dictionary --- Focus OK
2D Codes --- Iris OK
Circle Angle OK Unit Macro ---
Shape Search III --- Unit Calculation Macro ---
Intersection OK Parallelize ---
Barcode OK Parallelize Task ---
Some processing items are processed in parallel as individual units.
Note
