Alignment
318
Vision System FH/FZ5 Series
User’s Manual (Z340)
• Using the Flow
The motionless workpiece (or a saved image) is continuously measured until the calibration is completed.
This allows you to easily verify the operation of the calibration flow with the FH/FZ5-series Controller.
Conventionally, you could not verity the calibration flow unless the Controller was integrated into the
system.
Refer to Machine Simulator of the Vision System FH/FZ5 Series Processing Item Function Reference
Manual (Cat No. Z341).
↓
Position measurement processing item · · · Measure the position of the alignment marks or the position of a special
feature of the workpiece from the image in Camera 1.
To output the position on the image, set [Calibration] on the [Output
parameter] tab page to OFF.
Out of the general measurement processing items (Inspections and
Measurements), you can use processing items with measurement
results that have an X and Y in the calculation strings.
↓
Vision Master Calibration processing item · · ·
Set the machine setting processing item to reference, and then set the
sampling.
