Macro Reference
328
Vision System FH/FZ5 Series
User’s Manual (Z340)
Communication
--- IoModule
Serial (Ethernet)
UdpNormal: Normal (UDP)
TcpNormal: Normal (TCP)
TcpClient: Normal (TCP Client)
UdpNormal2: Normal (UDP) (Fxxx series method)
UdpPlcLink: PLC Link (SYSMAC CS/CJ/CP/One)
UdpPlcLinkM: PLC Link (MELSEC QnU/Q/QnAS series)
UdpPlcLinkY: PLC Link (JEPMC MP)
ioIdent2
Serial (RS-232C/422)
SerialNormal: Normal
SerialNormal2: Normal (Fxxx series method)
SerialPlcLink: PLC Link (SYSMAC CS/CJ/CP/One)
SerialPlcLinkM: PLC Link (MELSEC QnU/Q/QnAS series)
ioIdent1
Parallel
ParallelIo: Standard Parallel I/O
ioIdent0
Fieldbus
*1: Blank character: None
EtherCAT: EtherCAT
EtherNet/IP: EtherNet/IP
ioIdent3
Remote Operation
RemoteServer: Yes
*1: Blank character: None
ioIdent4
Multi-line Random-trigger
Mode Settings
--- MultiLineRandom
Number of lines (2/3/4/5/6/7/8) lineCount
Camera - line assignment 0 physicalCameraMask0
Camera - line assignment 1 physicalCameraMask1
Camera - line assignment 2 physicalCameraMask2
Camera - line assignment 3 physicalCameraMask3
Camera - line assignment 4 physicalCameraMask4
Camera - line assignment 5 physicalCameraMask5
Camera - line assignment 6 physicalCameraMask6
Camera - line assignment 7 physicalCameraMask7
Identifier information 0 Identifier information 1 Data identifier name
