Macro Reference
329
8
Appendices
Vision System FH/FZ5 Series
User’s Manual (Z340)
Camera settings
--- CameraControl
STEP - camera 0 delay cameraDelay0
STEP - camera 1 delay cameraDelay1
STEP - camera 2 delay cameraDelay2
STEP - camera 3 delay cameraDelay3
STEP - camera 4 delay cameraDelay4
STEP - camera 5 delay cameraDelay5
STEP - camera 6 delay cameraDelay6
STEP - camera 7 delay cameraDelay7
Baud rate 0
0: Normal
1: Fast
transferRate0
Baud rate 1
0: Normal
1: Fast
transferRate1
Baud rate 2
0: Normal
1: Fast
transferRate2
Baud rate 3
0: Normal
1: Fast
transferRate3
Baud rate 4
0: Normal
1: Fast
transferRate4
Baud rate 5
0: Normal
1: Fast
transferRate5
Baud rate 6
0: Normal
1: Fast
transferRate6
Baud rate 7
0: Normal
1: Fast
transferRate7
Output signal setting
0: STGOUT
1: SHTOUT
timingSignal
SHTOUT signal delay shtoutDelay
SHTOUT signal pulse width shtoutWidth
SHTOUT signal pulse polarity
0: Negative polarity
1: Positive polarity
shtoutPolarity
Identifier information 0 Identifier information 1 Data identifier name
