Omron SYSMAC FH Series

WWW.NNC.IR
Macro Reference
330
Vision System FH/FZ5 Series
User’s Manual (Z340)
Parallel
--- ParallelIo
Output polarity
0: ON at NG
1: ON at OK
polarity
Output control
0: OFF
1: Handshaking
2: Synchronization output
handshake
Output cycle cycleTime
Gate ON delay riseTime
Output time outputTime
Timeout timeout
Number of delay delayCount
One-shot OR signal
0: OFF
1: ON
orOutMode
OR signal output time orOutputTime
Normal
--- SerialNormal
Timeout timeout
Interface
0: RS-232C
1: RS-422
rsMode
Baud rate (2,400, 4,800, 9,600, 19,200, 38,400, 57,600, or
115,200)
baudRate
Data length (7 or 8) byteSize
Parity
0: OFF
1: Odd
2: Even
parity
Stop bits (1 or 2) stopBits
Flow control
0: OFF
1: Xon/Xoff
softFlow
Delimiter
0: CR
1: LF
2: CR + LF
delimiter
Identifier information 0 Identifier information 1 Data identifier name
