Vision System FH/FZ5 Series
User’s Manual (Z340)
Normal (Fxxx series method)
--- SerialNormal2
Timeout timeout
Interface
0: RS-232C
1: RS-422
rsMode
Baud rate (2,400, 4,800, 9,600, 19,200, 38,400, 57,600,
115,200)
baudRate
Data length (7 or 8) byteSize
Parity
0: OFF
1: Odd
2: Even
parity
Stop bits (1 or 2) stopBits
Flow control
0: OFF
1: Xon/Xoff
softFlow
Delimiter
0: CR
1: LF
2: CR + LF
delimiter
RS-232C/422 PLC Link
(SYSMAC CS/CJ/CP/One)
--- SerialPlcLink
Output control
0: OFF
1: Handshaking
handshake
Timeout timeout
Interface
0: RS-232C
1: RS-422
rsMode
Baud rate (2,400, 4,800, 9,600, 19,200, 38,400, 57,600,
115,200)
baudRate
Data length (7 or 8) byteSize
Parity
0: OFF
1: Odd
2: Even
parity
Stop bits (1 or 2) stopBits
Flow control
0: OFF
1: Xon/Xoff
softFlow
Delimiter
0: CR
1: LF
2: CR + LF
delimiter
Command Area type commandArea
Command Area address commandMemoryAddress
Response Area type responseArea
Response Area address responseMemoryAddress
Data Output Area type outputArea
Data Output Area address outputMemoryAddress
Identifier information 0 Identifier information 1 Data identifier name
