Editing Processing Units in Scenes
55
2
Setting Scenes (Measurement Flows)
Vision System FH/FZ5 Series
User’s Manual (Z340)
• If a processing unit is inserted, the numbers for the subsequent processing units increase by one. With processing items
related to results output or branch control, the numbers for processing units set as references also automatically
increase by one.
• If a button other than [Paste] is clicked after pasting a processing unit, continued pasting of the processing item cannot
be performed.
• If a processing unit is deleted, the numbers for the subsequent processing units decrease by one. With processing items
related to results output or branch control, the numbers for processing units set as references also automatically
decrease by one.
• To hide a specific processing unit in the flow on an adjustment window or run window, insert a "*" (single byte) at the
beginning of the processing unit name.
• The number of units that can be set in a flow depends on the available data memory.
With the FH or FZ5-11, a warning message is displayed when the amount of available application memory falls
below 1 GB. Adjust the inspection flow so that the available memory is more than 1 GB.
Reference: Checking System Information: [System Information] (p.300)
• When copying and pasting a conditional branch processing unit or other processing unit that refers to another processing
units, the branch destination of the pasted processing unit is initialized to [End processing]. When pasting whole
processing units within a folder, a parallelization processing unit, or a parallelized task processing unit, references from
inside the pasted block to outside the block are initialized to [End processing].
When copying and pasting a calculation processing unit or other processing unit that refers to another processing unit,
the content of the expression of the pasted processing unit becomes #ERR. When pasting whole processing units within
a folder, a parallelization processing unit, or a parallelized task processing unit, references from inside the pasted block
to outside the block become #ERR.
• Turning measurement execution ON/OFF for a folder, a parallelization processing unit or a parallelized task processing
unit turns measurement execution ON/OFF for all processing units within the folder, the parallelization processing unit or
the parallelized task processing unit.
• When [ON] is set for [Parallel Execute] in [Operation mode setting] in the system settings, turning the measurement
execution setting ON/OFF for a processing unit may greatly change the processing time. In this case, use parallelization
processing items to parallelize the measurement flow instead of using automatic parallel processing.
• When measurement execution has been set to OFF for a processing unit that is a conditional branch destination,
processing is executed starting with the first processing unit set to ON after the branch destination processing unit.
