Macro Reference
660
Vision System FH/FZ5 Series
User’s Manual (Z340)
RenumUnitNo
Gets the processing unit number after flow edit.
Format
RenumUnitNo(<oldUnitNo>)
Parameter
Return value
Returns the processing unit number after update of measurement flow as an integer.
Description
Gets the processing unit number specified in the <oldUnitNo> parameter after editing the measurement flow.
If an incorrect data type is specified for a parameter, a "Type mismatch" error will occur.
Even if a non-existent number, numerical value, or combination of data types or values is specified for the
parameter, an error will not occur.
If a value outside the range -2147483648 to 2147483647 is specified as an integer parameter, an "Overflow"
error will occur.
If a value is assigned to the return value variable or the variable is not used in an expression, a "Syntax error"
error will occur.
If the format is written incorrectly, such as writing the macro function name incorrectly, omitting a comma, or
omitting a half-width space, a "Syntax error" error will occur.
Besides using this macro function, using reference variables follows the changes of the processing unit
numbers resulting from editing the measurement flow. (Reference: XVariable (p.209))
Usage Cautions
• This macro function can only be used in the *RENUMPROC subroutine. If used in another subroutine, an
"Illegal function call" will occur.
Example
Uses the *RENUMPROC subroutine in the Unit Macro processing unit to get the processing unit number
(whose original processing unit number was 5) after editing the measurement flow.
Useable Modules
Unit Calculation Macro / Unit Macro
Parameter
name
Data type Description
<oldUnitNo> Integer type
Processing unit number before edit (0 to (Processing unit number of current scene minus
one))
*RENUMPROC
LATESTUNITNO& = 5
Rem Get the processing unit number after flow edit.
LATESTUNITNO& = RenumUnitNo(LATESTUNITNO&)
Return
