Macro Reference
659
8
Appendices
Vision System FH/FZ5 Series
User’s Manual (Z340)
Usage Cautions
• Execute this macro function when a measurement-in-progress signal such as the BUSY signal is OFF and
measurement is allowed. (Reference: XState Transitions and Execution Timing (p.227))
Example
In the communication command macro, gets the measurement X coordinate and measurement Y coordinate
of the search processing unit of Processing Unit number 2 after remeasurement is executed using the most
recent logging image. The measured X and Y coordinates can be gotten with External Reference Data
numbers 6 and 7 respectively.
Useable Modules
Scene Control Macro / Communication Command Macro
Supported Versions
Version 3.50 or later
Related Items
Rem Execute remeasurement and wait until measurement ends.
Remeasure 0, 1
Rem Get the measurement result.
GetUnitData 2, 6, POSX#
GetUnitData 2, 7, POSY#
MeasureStart (Reference: X Details (p.617)) MeasureStop (Reference: X Details (p.619))
Measure (Reference: X Details (p.612))
