15-12
WR902 FP0R
Relay No.
Name
Description
R9020 RUN mode flag
Turns off while the mode selector is set to PROG.
Turns on while the mode selector is set to RUN.
R9021
Not used
R9022
Not used
R9023
Not used
R9024
Not used
R9025
Not used
R9026
Message flag
Turns on while the F149 (MSG) instruction is executed.
R9027
Not used
R9028
Not used
R9029 Forcing flag
Turns on during forced on/off operation for input/output relay
timer/counter contacts.
R902A
Interrupt enable
flag
Turns on while the external interrupt trigger is enabled by the ICTL
instruction.
R902B
Interrupt error
flag
Turns on when an interrupt error occurs.
R902C Sample point flag
Sampling by the instruction=0
Sampling at constant time intervals=1
R902D
Sampling trace
end flag
When the sampling operation stops=1,
When the sampling operation starts=0
R902E
Sampling stop
trigger flag
When the sampling stop trigger activates=1
When the sampling stop trigger stops=0
R902F
Sampling enable
flag
When sampling starts=1
When sampling stops=0
A: Available, N/A: Not available
