5 Technical specifications Chapter A: General and technical data
12 Planmeca PlanMill 40 Technical manual
5 Technical specifications
The PlanMill 40 milling unit uses standard electrical current and compressed air, but it
does not connect to a water supply or drain.
5.1 Applicable standards
Table 1: Technical specifications and operating condition
Supply voltage 120/240 VAC 50/60 Hz
Power 300 W
Air supply requirements Pressure and flow:
• 3.5 bar - 9.0 bar (50 psi - 130 psi)
• minimum 60 l/min (2 CFM)
Air purity:
• Solid contaminants (Class 3); filtration level better
than 5 μm for solids.
• Water content (Class 4); maximum pressure dew
point +3°C.
• Total oil content (Class 3); maximum oil content 1
mg/m3.
Data connection Cat6 Ethernet cabling
Storage temperature -40°C to 70°C (-40°F to 158°F)
Operating conditions • 15°C - 38°C (50°F to 100°F)
• 0% - 90% relative humidity
• maximum altitude 2000 meters (6,562 feet)
Dimensions Width: 67,6 cm (26,6 in)
Height: 39,9 cm (15,7 in)
Depth: 60,5 cm (23,8 in)
Minimum required
clearances
Front: 61 cm (24 in)
Sides: 5 cm (2 in)
Rear: 2,5 cm (1 in)
Top: 30,5 cm (12 in)
Weight 100 kg (220 lb)
Electrical and mechanical safety UL 61010-1:2004 w/Rev 2008
CSA C22.2 No. 61010.1.04 w/Rev 2008
IEC 61010-1:2001, 2nd Edition
EN 61010-1
EMC IEC/EN 61326
