Technical manual Planmeca PlanMill 40 49
Chapter C: Calibration
1 Overview
The PlanMill 40 unit must be calibrated to operate correctly and achieve the high degree of
accuracy required for the dental restorations.
To check the calibration of the PlanMill 40, see instructions in section 5 "Verifying
calibration" on page 67.
The actual calibration is separated into following steps:
1. Tool changer calibration
2. Profile sensor calibration
3. Origin calibration
4. Verifying calibration
5. Refine 2 calibration (if needed)
The calibration process should be performed in the order listed above. The order of
dependencies is such that you may start with any of the steps, however you must always
perform the remaining procedures.
E.g. if you start from step 2 (Profile sensor calibration), you must go through also steps 3,
4 and 5.
Before making any procedures that require tool changer, profile sensor or origin calibration,
remove all tools from the tool changer and the spindles.
