5-126 Menus and Commands
6-00054-02 Rev A
storage cell section (1–4), drive
bay (1–2), or IE station
number.
The fourth field indicates the
column of the section (A–E),
drive port (A–B), or IE station
column.
The fifth field indicates the
row of the column.
(01–12 for ½-inch and SDLT/
DLT coordinates)
(01–14 for LTO coordinates)
(01–18 for AIT coordinates)
Element Displays the element number
that corresponds to the
coordinate parameter.
Accept Y to accept changes
N to reject changes
If Y is selected for the Accept parameter value, the
Number of Drives Dialog appears. See Figure 5-174.
Otherwise, the changed parameters continue to display
but no action is taken.
Figure 5-174 Number of Drives Dialog
Parameter Value
Get/Put Selects the number of
elements where the Get/Put
operation is applied
(0000–0048 for all elements).
Accept Y to accept changes
N to reject changes
Number of Drives
to Get/Put : 0010<
Accept : N
