Return values:
<Result> Default unit: DBM
Manual operation: See " Marker Table " on page 413
See " Marker Peak List " on page 413
14.8.3.6 Marker Search (Spectrograms)
The following commands automatically define the marker and delta marker position in
the spectrogram.
The usage of these markers is demonstrated in Chapter 14.8.2.7, "Programming
Example: Configuring a Spectrogram", on page 979.
Using Markers
The following commands control spectrogram markers.
Useful commands for spectrogram markers described elsewhere
The following commands define the horizontal position of the markers.
●
CALCulate<n>:MARKer<m>:MAXimum:LEFT on page 994
●
CALCulate<n>:MARKer<m>:MAXimum:NEXT on page 994
●
CALCulate<n>:MARKer<m>:MAXimum[:PEAK] on page 994
●
CALCulate<n>:MARKer<m>:MAXimum:RIGHt on page 995
●
CALCulate<n>:MARKer<m>:MINimum:LEFT on page 995
●
CALCulate<n>:MARKer<m>:MINimum:NEXT on page 996
●
CALCulate<n>:MARKer<m>:MINimum[:PEAK] on page 996
●
CALCulate<n>:MARKer<m>:MINimum:RIGHt on page 996
Remote commands exclusive to spectrogram markers
CALCulate<n>:MARKer<m>:SGRam:FRAMe................................................................. 1002
CALCulate<n>:MARKer<m>:SPECtrogram:FRAMe.........................................................1002
CALCulate<n>:MARKer<m>:SGRam:SARea..................................................................1002
CALCulate<n>:MARKer<m>:SPECtrogram:SARea......................................................... 1002
CALCulate<n>:MARKer<m>:SGRam:XY:MAXimum[:PEAK].............................................1003
CALCulate<n>:MARKer<m>:SPECtrogram:XY:MAXimum[:PEAK].................................... 1003
CALCulate<n>:MARKer<m>:SGRam:XY:MINimum[:PEAK]..............................................1003
CALCulate<n>:MARKer<m>:SPECtrogram:XY:MINimum[:PEAK]..................................... 1003
CALCulate<n>:MARKer<m>:SGRam:Y:MAXimum:ABOVe...............................................1003
CALCulate<n>:MARKer<m>:SPECtrogram:Y:MAXimum:ABOVe...................................... 1003
CALCulate<n>:MARKer<m>:SGRam:Y:MAXimum:BELow............................................... 1003
CALCulate<n>:MARKer<m>:SPECtrogram:Y:MAXimum:BELow.......................................1003
CALCulate<n>:MARKer<m>:SGRam:Y:MAXimum:NEXT.................................................1003
CALCulate<n>:MARKer<m>:SPECtrogram:Y:MAXimum:NEXT........................................ 1003
CALCulate<n>:MARKer<m>:SGRam:Y:MAXimum[:PEAK]...............................................1004
