Remote Commands
R&S
®
FSVA3000/ R&S
®
FSV3000
770User Manual 1178.8520.02 ─ 01
MSR Adjacent Channel Setup
The functions for manual operation are described in Chapter 7.3.5, "MSR ACLR Con-
figuration", on page 167.
Useful commands for MSR adjacent channel setup described elsewhere:
●
Chapter 14.5.3.5, "Checking Limits", on page 760
●
"MSR Channel Names" on page 780
Remote commands exclusive to MSR adjacent channel setup:
[SENSe:]POWer:ACHannel:SBLock<sb>:RFBWidth..........................................................770
[SENSe:]POWer:ACHannel:SBLock<sb>:TECHnology[:CHANnel<ch>]...............................770
[SENSe:]POWer:ACHannel:SBLock<sb>:TXCHannel:COUNt............................................ 771
[SENSe:]POWer:ACHannel:SPACing:UACHannel.............................................................771
[SENSe:]POWer:ACHannel:SPACing:UALTernate<ch>......................................................772
[SENSe:]POWer:ACHannel:SSETup................................................................................772
[SENSe:]POWer:ACHannel:BWIDth:UACHannel...............................................................772
[SENSe:]POWer:ACHannel:BANDwidth:UACHannel......................................................... 772
[SENSe:]POWer:ACHannel:BWIDth:UALTernate<ch>........................................................773
[SENSe:]POWer:ACHannel:BANDwidth:UALTernate<ch>.................................................. 773
[SENSe:]POWer:ACHannel:FILTer:ALPHa:UACHannel......................................................773
[SENSe:]POWer:ACHannel:FILTer:ALPHa:UALTernate<ch>...............................................773
[SENSe:]POWer:ACHannel:FILTer[:STATe]:UACHannel.....................................................774
[SENSe:]POWer:ACHannel:FILTer[:STATe]:UALTernate<ch>..............................................774
[SENSe:]POWer:ACHannel:SBLock<sb>:RFBWidth <Bandwidth>
This command defines the bandwidth of the individual MSR sub block. Note that sub
block ranges also affect the position of the adjacent gap channels (CACLR).
This command is for MSR signals only (see CALCulate<n>:MARKer<m>:
FUNCtion:POWer<sb>:PRESet on page 752).
Suffix:
<sb>
.
1..n
sub block number
Parameters:
<Bandwidth> Bandwidth in Hz
Default unit: Hz
Manual operation: See " RF Bandwidth " on page 173
[SENSe:]POWer:ACHannel:SBLock<sb>:TECHnology[:CHANnel<ch>]
<Standard>
This command defines the technology used for transmission by the specified MSR Tx
channel.
This command is for MSR signals only (see CALCulate<n>:MARKer<m>:
FUNCtion:POWer<sb>:PRESet on page 752).
Configuring and Performing Measurements
