PG-FP6 V1.06 Appendix A. Messages
R20UT4469EJ0800 Rev.8.00 Page 164 of 188
Oct.01.21
An attempt was made to connect a target device which differs from that when the settings
file was created. Create a new settings file or use the correct settings file with the target
device.
Invalid signature
code.
An attempt was made to connect a target device which differs from that when the settings
file was created. Create a new settings file or use the correct settings file with the target
device.
Invalid signature
code.
An attempt was made to connect a target device which differs from that when the settings
file was created. Create a new settings file or use the correct settings file with the target
device.
Invalid signature
code.
An attempt was made to connect a target device which differs from that when the settings
file was created or the memory structure might have been changed by the option settings
of the target device. Create a new settings file. Refer to section 12.2, Problems during
Operation.
Invalid signature
code.
024 Inv. device name An attempt was made to connect a target device which differs from that when the settings
file was created. Create a new settings file or use the correct settings file with the target
device.
code.
026 Inv. Dev/Firm ver An attempt was made to connect a target device which differs from that when the settings
file was created. Create a new settings file or use the correct settings file with the target
device.
firmware version.
027 Unkn. Signature The parameter file downloaded to the FP6 may have been damaged. Download the
parameter file to the FP6 again.
code.
029 Inv. DeviceInfo Check the correctness of the correspondence between the parameter file downloaded to
the FP6 and the connected MCU.
Synchronisation
failed.
034 Endian info err A timeout occurred when a problem in communications between the target device and the
FP6 arose for some reason. Check the connection to the target device and confirm that the
target device has not been reset. Refer to section 12.2, Problems during Operation.
failure or timeout.
040 Erase Timeout A timeout occurred when a problem in communications between the target device and the
FP6 arose for some reason. Check the connection to the target device and confirm that the
target device has not been reset. Refer to section 12.2, Problems during Operation.
failure or timeout.
041 Erase failure This error code and message are displayed when erasure of flash memory in the target
device was attempted but failed.
Possible causes of the error (failure to erase) include:
(1) The power-supply voltage for the target device not being correct.
(2) Flash memory in the target device cannot be erased because of the pin settings or
processing.
(3) An operation was attempted in an area that is restricted by a security function.
Check the items (1) through (3) above.
If this error is not resolved even if there are none of the problems described in (1) through
(3) above, the target device may be malfunctioning (including defects in or deterioration of
the flash memory).
Protect error due
to Security
Setting
error (0xXX)
A timeout occurred when a problem in communications between the target device and the
FP6 arose for some reason. Check the connection to the target device and confirm that the
target device has not been reset. Refer to section 12.2, Problems during Operation.
Communication
failure or timeout.
This error code and message are displayed when blank checking is executed for the flash
memory of the target device and the area is not blank.
When the target device is to be programmed, erase the flash memory with the ‘ers’
command before executing the ‘prg’ command or execute the ‘ep’ command.
Not Blank.
