Renesas PG-FP6 V1.06

PG-FP6 V1.06 Appendix A. Messages
R20UT4469EJ0800 Rev.8.00 Page 165 of 188
Oct.01.21
No.
Message
Possible Workaround
070
Write timeout
A timeout occurred when a problem in communications between the target device and the
FP6 arose for some reason. Check the connection to the target device and confirm that the
target device has not been reset. Refer to section 12.2, Problems during Operation.
Communication
failure or timeout.
071
Write failed
This error code and message are displayed when programming of flash memory in the
target device was attempted but failed.
Possible causes of the error (failure to program) include:
(1) Programming was attempted in an area where the flash memory had not been erased.
(2) The power-supply voltage for the target device not being correct.
(3) Flash memory in the target device cannot be programmed because of the pin settings
or processing.
(4) An operation was attempted in an area that is restricted by a security function.
Check the items (1) through (4) above.
If this error is not resolved even if there are none of the problems described in (1) to (4)
above, the target device may be malfunctioning (including defects in or deterioration of the
flash memory).
Program failed
Protect error due
to Security
Setting
Receive device
error (0xXX)
074 No Prog Data The operation area contains no data for the program file. Check the block setting and
program file downloaded to the FP6.
There is no data
in the operating
range.
075 No Flash Option The flash option settings have not been specified in the setting file.
When using the Program Flash Option command (pfo command), specify the flash option
settings.
No flash options
have been set.
080 Vrf Timeout A timeout occurred when a problem in communications between the target device and the
FP6 arose for some reason. Check the connection to the target device and confirm that the
target device has not been reset. Refer to section 12.2, Problems during Operation.
Communication
failure or timeout.
081 Verify failed This error code and message are displayed when verification of flash memory in the target
device was attempted but failed.
Possible causes of the error include:
(1) Different data have been written to the program file and the target device.
(2) The power-supply voltage for the target device not being correct.
(3) Data cannot be read from flash memory in the target device because of the pin settings
or processing.
Check the items (1) through (3) above.
If this error is not resolved even if there are none of the problems described in (1) to (3)
above, the target device may be malfunctioning (including defects in or deterioration of the
flash memory).
Receive device
error (0xXX)
090
IVrf Timeout
A timeout occurred when a problem in communications between the target device and the
FP6 arose for some reason. Check the connection to the target device and confirm that the
target device has not been reset. Refer to section 12.2, Problems during Operation.
Communication
failure or timeout.
091
IVerify failed
An error occurred while the flash memory of the target device was being programmed.
Erase the flash memory before programming. Also, check that the power-supply voltage
for the target device is normal. If the same error occurs even if you try the operation again,
the target device may be malfunctioning (including defects in or deterioration of the flash
memory).
Internal Verify
failed
093 SUM Comm err An error occurred during execution of the ‘sum’ command. This might be due to a problem
with communications between the FP6 and target device. Refer to section 12.2, Problems
during Operation.
Communication
failure or timeout.
