Risco ProSYS Plus - Page 114

11
/
2017 Page 114 5IN2413 B
Quick keys Parameter Default Range
 
At Stay
Set the sound produced when a system's zone triggers an alarm while the
system is partially (Stay) armed.
 
At Disarm
Set the sound produced when a system's zone triggers an alarm while the
system is disarmed.
Zones  Parameters  By Category  Termination
Quick keys Parameter Default Range

Termination
The Termination menu enables you to program the connection type used
for each of the system's zones. The actual (physical) termination for each
zone must comply with that selected in the zone termination menu.
1. Select the zone (ZZZ) and then press OK.
2. Then scroll to select the zone termination resistance type (see below),
and press OK.

N/C
Uses normally-closed contacts and no terminating End-of-Line Resistance

EOL
Uses normally-closed (NC) contacts in a zone terminated by End-of-Line
Resistance.

DEOL
Uses normally-closed (NC) contacts in a zone terminated by Double End-
of-Line Resistance to distinguish between alarm and tamper conditions
on the same zone.

N/O
Uses normally-open contacts and no terminating End-of-Line Resistance.

TEOL
Uses normally-closed (NC) contacts in a zone terminated by Triple End-
of-Line Resistance to distinguish between alarm, tamper and anti-mask
conditions on the same zone.
