Quick keys Parameter Default Range
• A utility output defined as “Auto Arm Alarm” is deactivated.
• A utility output defined as “Zone Loss Alarm” is deactivated.
• Guard User: If a Guard user disarms a partition, the system will be
armed automatically after the predefined time period (see
Guard
Delay
page 80). If there is an open zone during the arming process,
the partition will be bypassed.
Disable Incoming Calls
No Yes/No
This parameter is used to disable all incoming calls trying to come in
through the voice channel (GSM).
YES: Incoming calls from voice channel are disabled.
NO: Incoming calls from voice channel are enabled.
Note
Incoming data call via the GSM data channel is still enabled
Disable Keypad When
Auto Disarm Exists
No Yes/No
YES: When a partition is armed manually or in auto arm mode, and an
auto disarm time is defined, this parameter specifies that all the keypads
that are masked to this partition will not function and that it will be
impossible to disarm the relevant partition.
Note
The partition can be disarmed only by using the Configuration Software or
the Auto Disarm function.
NO: When a partition is armed manually or in Auto Arm mode, and an
auto disarm time is defined, the relevant keypads will function normally.
Buzzer Delay
No Yes/No
YES: The keypad buzzer will be silent during the bell delay time.
NO: The keypad buzzer will be audible immediately when a system alarm
occurs.
Speaker = Buzzer
No Yes/No
YES: The internal sounder will follow the operation of any keypad’s
buzzer.
NO: The internal sounder will follow the external sounder operation (and
not the keypad’s buzzer).
