7K • Chapter 7
7-8
Select (Review) Autopatch Error Messages
One of these messages is sent over the repeater transmitter when
a telephone number cannot be dialed.
• The Off Message is sent when the Autopatch is off.
• The Busy Message is sent when the Busy Logic Input is active.
• The Reject Message is sent when the phone number entered by the user
or programmed in a macro matches an entry in the Reject Table.
• The Error Message is sent when a phone number entered by the user or
programmed in a macro does not match one of the enabled Call Types or
Accept Table entries.
• The No-Redial-Number Message is sent when a redial command has
been entered and there is no phone number in the redial buffer.
• If an autopatch message is not programmed, the default CW message will
be sent only when Command Responses are enabled.
Command Form:
Command Form Default
Select Autopatch Off Message (PW) 31 44 (message) * OFF in CW
Select Autopatch Busy Message (PW) 31 42 (message) * BZ in CW
Select Autopatch Reject Message (PW) 31 46 (message) * ?REJ in CW
Select Autopatch Error Message (PW) 31 45 (message) * ?ERR in CW
Select Autopatch No-Redial-Number
Message
(PW) 31 47 (message) * CLR in CW
Review Autopatch Off Message (PW) 34 44 * none
Review Autopatch Busy Message (PW) 34 42 * none
Review Autopatch Reject Message (PW) 34 46 * none
Review Autopatch Error Message (PW) 34 45 * none
Review Autopatch No-Redial-Number
Message
(PW) 34 47 * none
Acknowledgment: Sends OK
Errors:
Error Meaning
? err 1 wrong number of digits entered
? err 2 illegal digit entered
Default Condition: The default CW message is sent only if Command
Responses are enabled.
