Command Quick Reference
Page Command Name Form and Data Digit Default User
13-2 Enable/Disable Path 7 (Rx1 to AP) (PW) 63 87 x *
0 = OFF (disabled
1 = ON (enabled)
ON
enabled
13-2 Enable/Disable Path 8 (Rx2 to AP) (PW) 63 88 x *
0 = OFF (disabled
1 = ON (enabled)
OFF
disabled
13-2 Enable/Disable Path 9 (Rx3 to AP) (PW) 63 89 x *
0 = OFF (disabled
1 = ON (enabled)
OFF
disabled
13-2 Enable/Disable Path 10 (AP to Tx1) (PW) 63 90 x *
0 = OFF (disabled
1 = ON (enabled)
ON
enabled
13-2 Enable/Disable Path 11 (AP to Tx2) (PW) 63 91 x *
0 = OFF (disabled
1 = ON (enabled)
OFF
disabled
13-3 Select Receiver-to-Tx1 Audio Routing
Priority
(PW) 90 00 x x x *
x = 1, 2, 3
1 = Rx1, 2 = Rx2, 3 = Rx3
Routing
Priorities:
Rx1, Rx2,
Rx3
13-3 Select Receiver-to-Tx2 Audio Routing
Priority
(PW) 90 01 x x x *
x = 1, 2, 3
1 = Rx1, 2 = Rx2, 3 = Rx3
Routing
Priorities:
Rx1, Rx2,
Rx3
13-3 Select Receiver-to-Autopatch Audio
Routing Priority
(PW) 90 02 x x x *
x = 1, 2, 3
1 = Rx1, 2 = Rx2, 3 = Rx3
Routing
Priorities:
Rx1, Rx2,
Rx3
13-3 Select Receiver-to-Phone Line Monitor
Audio Routing Priority
(PW) 90 03 x x x *
x = 1, 2, 3
1 = Rx1, 2 = Rx2, 3 = Rx3
Routing
Priorities:
Rx1, Rx2,
Rx3
13-4 Select Rx1-to-Tx1 Access Mode (Path 1) (PW) 57 00 x *
0 = no access
1 = carrier access
2 = PL access
3 = And-PL access
4 = Or-PL access
5 = Anti-PL access
6 = Always access
1
carrier
access
13-4 Select Rx2-to-Tx1 Access Mode (Path 2) (PW) 57 01 x *
Same as above
1
carrier
access
13-4 Select Rx3-to-Tx1 Access Mode (Path 3) (PW) 57 02 x *
Same as above
1
carrier
access
13-4 Select Rx1-to-Tx2 Access Mode (Path 4) (PW) 57 03 x *
Same as above
1
carrier
access
13-4 Select Rx2-to-Tx2 Access Mode (Path 5) (PW) 57 04 x *
Same as above
1
carrier
access
13-4 Select Rx3-to-Tx2 Access Mode (Path 6) (PW) 57 05 x *
Same as above
1
carrier
access
