Programming Tables
A-45
Command Quick Reference
Page Command Name Form and Data Digit Default User
14-1
Logic Inputs
14-2 Assign Macro to Logic Input 1 Hi-to-Lo (PW) 26 20 (macro name) * none
14-2 Assign Macro to Logic Input 1 Lo-to-Hi (PW) 26 21 (macro name) * none
14-2 Assign Macro to Logic Input 2 Hi-to-Lo (PW) 26 22 (macro name) * none
14-2 Assign Macro to Logic Input 2 Lo-to-Hi (PW) 26 23 (macro name) * none
14-2 Assign Macro to Logic Input 3 Hi-to-Lo (PW) 26 24 (macro name) * none
14-2 Assign Macro to Logic Input 3 Lo-to-Hi (PW) 26 25 (macro name) * none
14-2 Assign Macro to Logic Input 4 Hi-to-Lo (PW) 26 26 (macro name) * none
14-2 Assign Macro to Logic Input 4 Lo-to-Hi (PW) 26 27 (macro name) * none
14-2 Assign Macro to Logic Input 5 Hi-to-Lo (PW) 26 28 (macro name) * none
14-2 Assign Macro to Logic Input 5 Lo-to-Hi (PW) 26 29 (macro name) * none
14-2 Assign Macro to Logic Input 6 Hi-to-Lo (PW) 26 30 (macro name) * none
14-2 Assign Macro to Logic Input 6 Lo-to-Hi (PW) 26 31 (macro name) * none
14-2 Assign Macro to Phone Line Busy Input
Hi-to-Lo
(PW) 26 32 (macro name) * none
14-2 Assign Macro to Phone Line Busy Input
Lo-to-Hi
(PW) 26 33 (macro name) * none
14-2 Assign Macro to COR Input 1 Hi-to-Lo (PW) 26 34 (macro name) * none
14-2 Assign Macro to COR Input 1 Lo-to-Hi (PW) 26 35 (macro name) * none
14-2 Assign Macro to COR Input 2 Hi-to-Lo (PW) 26 36 (macro name) * none
14-2 Assign Macro to COR Input 2 Lo-to-Hi (PW) 26 37 (macro name) * none
14-2 Assign Macro to COR Input 3 Hi-to-Lo (PW) 26 38 (macro name) * none
14-2 Assign Macro to COR Input 3 Lo-to-Hi (PW) 26 39 (macro name) * none
14-2 Assign Macro to PL Input 1 Hi-to-Lo (PW) 26 40 (macro name) * none
14-2 Assign Macro to PL Input 1 Lo-to-Hi (PW) 26 41 (macro name) * none
14-2 Assign Macro to PL Input 2 Hi-to-Lo (PW) 26 42 (macro name) * none
14-2 Assign Macro to PL Input 2 Lo-to-Hi (PW) 26 43 (macro name) * none
14-2 Assign Macro to PL Input 3 Hi-to-Lo (PW) 26 44 (macro name) * none
14-2 Assign Macro to PL Input 3 Lo-to-Hi (PW) 26 45 (macro name) * none
15-1
Logic Outputs
15-2 Select Logic Outputs Latched OFF (PW) 71 (list of outputs 1-7) * all OFF
disabled
15-2 Select Logic Outputs Latched ON (PW) 70 (list of outputs 1-7) * all OFF
disabled
15-2 Select Logic Outputs Momentary OFF (PW) 73 (list of outputs 1-7) * all OFF
disabled
15-2 Select Logic Outputs Momentary ON (PW) 72 (list of outputs 1-7) * all OFF
disabled
16-1
Receiver Functions
16-2 Select Rx1 Start-of-Activity Macro (PW) 26 67 (macro name) * none
