S-COM 7K - Page 346

7K • Appendix A
A-46
Command Quick Reference
Page Command Name Form and Data Digit Default User
16-2 Select Rx1 Post-Activity Macro (PW) 26 68 (macro name) * none
16-2 Select Rx2 Start-of-Activity Macro (PW) 26 69 (macro name) * none
16-2 Select Rx2 Post-Activity Macro (PW) 26 70 (macro name) * none
16-2 Select Rx3 Start-of-Activity Macro (PW) 26 71 (macro name) * none
16-2 Select Rx3 Post-Activity Macro (PW) 26 72 (macro name) * none
16-2 Select Rx1 Post-Activity Timer (PW) 99 00 xx *
(00-99) = 0.0-9.9 minutes.
1.0 minute
16-2 Select Rx2 Post-Activity Timer (PW) 99 01 xx *
(00-99) = 0.0-9.9 minutes.
1.0 minute
16-2 Select Rx3 Post-Activity Timer (PW) 99 02 xx *
(00-99) = 0.0-9.9 minutes.
1.0 minute
16-4 Select COR Pulse-Triggered Macro (PW) 26 17 (macro name) * none
16-4 Select COR Pulse Parameters (PW) 47 0 x yyyy zzzz *
x = pulse count
(0-9) = 0-9 pulses
0 = 0 pulses
1 = 1 pulse
5 = 5 pulses ... etc.
y = minimum duration
(0001-9999) = 0.01-99.99 seconds
0001 = 0.01 seconds
0010 = 0.10 seconds
0100 = 1.00 seconds
1000 = 10.00 seconds
9999 = 99.99 seconds ... etc.
z = window time
Same as minimum duration
3 pulses,
0.5 second
minimum
duration,
5.0 second
window
time
16-6 Enable/Disable End-of-Transmission
Command Execution for Rx1
(PW) 63 57 x *
0 = OFF (disabled)
1 = ON (enabled)
OFF
disabled
(*) required
to
terminate
commands
16-6 Enable/Disable End-of-Transmission
Command Execution for Rx2
(PW) 63 58 x *
0 = OFF (disabled)
1 = ON (enabled)
OFF
disabled
(*) required
to
terminate
commands
16-6 Enable/Disable End-of-Transmission
Command Execution for Rx3
(PW) 63 59 x *
0 = OFF (disabled)
1 = ON (enabled)
OFF
disabled
(*) required
to
terminate
commands
16-8 Enable/Disable From-Start-of-
Transmission Timer for Rx1
(PW) 63 64 x *
0 = OFF (disabled)
1 = ON (enabled)
OFF
disabled
16-8 Enable/Disable From-Start-of-
Transmission Timer for Rx2
(PW) 63 65 x *
0 = OFF (disabled)
1 = ON (enabled)
OFF
disabled
