S-COM 7K - Page 347

Programming Tables
A-47
Command Quick Reference
Page Command Name Form and Data Digit Default User
16-8 Enable/Disable From-Start-of-
Transmission Timer for Rx3
(PW) 63 66 x *
0 = OFF (disabled)
1 = ON (enabled)
OFF
disabled
17-1
Transmitter Functions
17-3 Select Courtesy Delay (PW) 32 xx *
(00-50) = 0.0-5.0 seconds
00 = 0.0 seconds
05 = 0.5 seconds
10 = 1.0 seconds
50 = 5.0 seconds ... etc.
0.0
seconds
17-4 Select Dropout Delay (PW) 30 xx *
(00-50) = 0.0-5.0 seconds
00 = 0.0 seconds
05 = 0.5 seconds
10 = 1.0 seconds
50 = 5.0 seconds ... etc.
3.0
seconds
17-5 Select Transmitter Timeout Timer (PW) 40 xxx *
(001-546) = 0.1-54.6 minutes
000 = infinity
001 = 0.1 minute
030 = 3.0 minutes
546 = 54.6 minutes ... etc.
3.0
minutes
17-7 Reset Transmitter Timeout Timer (PW) 10 * none
17-8 Enable/Disable Transmitter 1 (PW) 63 00 x *
0 = OFF (disabled)
1 = ON (enabled)
ON
enabled
17-8 Enable/Disable Transmitter 2 (PW) 63 22 x *
0 = OFF (disabled)
1 = ON (enabled)
ON
enabled
17-9 Key Transmitter (Timed) (PW) 00 x yyy *
x = transmitter
1 = Tx1
2 = Tx2
y = duration
000 = cancel tx key
(001-546) = 0.1-54.6 minutes
001 = 0.1 minute
010 = 1.0 minute
100 = 10.0 minutes
546 = 54.6 minutes ... etc.
Tx1 and
Tx2 not
requested
to key
17-10 Key Transmitter 1 (Untimed) (PW) 63 41 x *
0 = cancel tx key
1 = key tx
0
cancel tx
key
17-10 Key Transmitter 2 (Untimed) (PW) 63 42 x *
0 = cancel tx key
1 = key tx
0
cancel tx
key
17-11 Enable/Disable Tx1 Minimum Unkey
Delay
(PW) 63 31 x *
0 = OFF (disabled)
1 = ON (enabled)
ON
enabled
17-11 Enable/Disable Tx2 Minimum Unkey
Delay
(PW) 63 32 x *
0 = OFF (disabled)
1 = ON (enabled)
OFF
disabled
