7.45
Date Code 20060320 Instruction Manual SEL-311C Relay
Inputs, Outputs, Timers, and Other Control Logic
Rotating Default Display (Only on Models With LCD)
MWBDI M W B I N D E M = x . x x x B demand megawatts in
MWBPI M W B I N P K = x . x x x B peak megawatts in
MWCDI M W C I N D E M = x . x x x C demand megawatts in
MWCPI M W C I N P K = x . x x x C peak megawatts in
MW3DI M W 3 I N D E M = x . x x x Three-phase demand megawatts in
MW3PI M W 3 I N P K = x . x x x Three-phase peak megawatts in
MVRADI M V R A I D E M = x . x x x A demand megavars in
MVRAPI M V R A I P K = x . x x x A peak megavars in
MVRBDI M V R B I D E M = x . x x x B demand megavars in
MVRBPI M V R B I P K = x . x x x B peak megavars in
MVRCDI M V R C I D E M = x . x x x C demand megavars in
MVRCPI M V R C I P K = x . x x x C peak megavars in
MVR3DI M V R 3 I D E M = x . x x x Three-phase demand megavars in
MVR3PI M V R 3 I P K = x . x x x Three-phase peak megavars in
MWADO M W A O D E M = x . x x x A demand megawatts out
MWAPO M W A O P K = x . x x x A peak megawatts out
MWBDO M W B O D E M = x . x x x B demand megawatts out
MWBPO M W B O P K = x . x x x B peak megawatts out
MWCDO M W C O D E M = x . x x x C demand megawatts out
MWCPO M W C O P K = x . x x x C peak megawatts out
MW3DO M W 3 O D E M = x . x x x Three-phase demand megawatts out
MW3PO M W 3 O P K = x . x x x Three-phase peak megawatts out
MVRADO M V R A O D E M = x . x x x A demand megavars out
MVRAPO M V R A O P K = x . x x x A peak megavars out
MVRBDO M V R B O D E M = x . x x x B demand megavars out
MVRBPO M V R B O P K = x . x x x B peak megavars out
MVRCDO M V R C O D E M = x . x x x C demand megavars out
MVRCPO M V R C O P K = x . x x x C peak megavars out
MVR3DO M V R 3 O D E M = x . x x x Three-phase demand megavars out
MVR3PO M V R 3 O P K = x . x x x Three-phase peak megavars out
MWHAI M W h A I N = x x . x x x A megawatt-hours in
MWHAO M W h A O U T = x x . x x x A megawatt-hours out
MWHBI M W h B I N = x x . x x x B megawatt-hours in
MWHBO M W h B O U T = x x . x x x B megawatt-hours out
MWHCI M W h C I N = x x . x x x C megawatt-hours in
MWHCO M W h C O U T = x x . x x x C megawatt-hours out
MWH3I M W h 3 I N = x x . x x x Three-phase megawatt-hours in
MWH3O M W h 3 O U T = x x . x x x Three-phase megawatt-hours out
MVRHAI M V A R h A I = x x . x x x A megavar-hours in
MVRHAO M V A R h A O = x x . x x x A megavar-hours out
MVRHBI M V A R h B I = x x . x x x B megavar-hours in
Table 7.11 Mnemonic Settings for Metering on the Rotating Default Display (Sheet 2 of 3)
Mnemonic Display Description
