7.47
Date Code 20060320 Instruction Manual SEL-311C Relay
Inputs, Outputs, Timers, and Other Control Logic
Rotating Default Display (Only on Models With LCD)
To program a display point to display one of the Breaker Monitor outputs
above, first enter the two-character sequence :: (double colon) followed by the
name of the desired breaker monitor output (e.g., EXTTR, CTRLTR,
CTRLIA, etc.).
If the display point setting does not match the format correctly, the relay will
display the setting text string as it was actually entered, without substituting
the breaker monitor output value.
Displaying Breaker
Monitor Outputs
Example
This example demonstrates use of the rotating display to show metering
quantities automatically on the rotating default display. This example will set
the EXTTR CTRLTR, CTRLIA, EXTIA, and WEARA to display in the
rotating default display.
Set the following:
Setting DPn = 0 and using the DPn_0 in the text settings allows the setting to
permanently rotate in the display. The DPn logic equation can be set to control
the text display-turning it on and off under certain conditions. With the relay
set as shown above, the LCD will show the following:
Table 7.13 Mnemonic Settings for Self-Check Status on the Rotating Default Display
Mnemonic Display Description
BRKDATE R S T D A T : m m / d d / y y last reset date
BRKTIME R S T T I M : h h : m m : s s last reset time
CTRLTR C T R L T R I P S = x x x x x internal trip count
OPSCNTR O P S C N T R = x x x x x internal trip count
CTRLIA C T R L I A = x x x x x k A internal trip Σ IA
CTRLIB C T R L I B = x x x x x k A internal trip Σ IB
CTRLIC C T R L I C = x x x x x k A internal trip Σ IC
EXTTR E X T T R I P S = x x x x x external trip count
EXTIA E X T I A = x x x x x k A external trip Σ IA
EXTIB E X T I B = x x x x x k A external trip Σ IB
EXTIC E X T I C = x x x x x k A external trip Σ IC
WEARA W E A R A = y y y % A phase wear monitor
WEARB W E A R B = y y y % B phase wear monitor
WEARC W E A R C = y y y % C phase wear monitor
Table 7.14 Settings for Displaying Breaker Monitor Outputs Example
SET T SET L
DP1_0 = ::EXTTR DP1 = 0
DP2_0 = ::CTRLTR DP2 = 0
DP3_0 = ::CTRLIA DP3 = 0
DP4_0 = ::EXTIA DP4 = 0
DP5_0 = ::WEARA DP5 = 0
