D.3
Date Code 20060320 Instruction Manual SEL-311C Relay
Configuration, Fast Meter, and Fast Operate Commands
Message Definitions
Message Definitions
A5C0 Relay
Definition Block
In response to the A5C0 request, the relay sends the block shown in Table D.3.
A5C1 Fast Meter
Configuration Block
In response to the A5C1 request, the relay sends the block shown in Table D.4.
Table D.3 A5C0 Relay Definition Block
Data Description
A5C0 Command
34 Message length (74)
04 Support SEL, LMD, DNP3, and R6 SEL protocols
03 Support Fast Meter, fast demand, and fast peak
03 Status flag for Warn, Fail, Group, or Settings change
A5C1 Fast Meter configuration
A5D1 Fast Meter message
A5C2 Fast demand configuration
A5D2 Fast demand message
A5C3 Fast peak configuration
A5D3 Fast peak message
0004 Settings change bit
A5C100000000 Reconfigure Fast Meter on settings change
0004 Settings change bit
A5C200000000 Reconfigure demand FM on settings change
0004 Settings change bit
A5C300000000 Reconfigure peak demand FM on settings change
0300 SEL protocol has Fast Operate
0101 LMD protocol has Fast Operate
0005 DNP3
0006 R6 SEL (relay-to-relay) M
IRRORED BITS
®
protocol
00 Reserved
xx Checksum
Table D.4 A5C1 Fast Meter Configuration Block (Sheet 1 of 3)
Data Description
A5C1 Fast Meter command
84 Length
01 One status flag byte
00 Scale factors in Fast Meter message
00 No scale factors
0A # of analog input channels
02 # of samples per channel
36 # of digital banks
01 One calculation block
