Section 9
Setting the Relay
Overview
Change or view settings with the SET and SHOWSET serial port commands
and the front-panel {SET} pushbutton. Table 9.1 lists the serial port SET
commands.
View settings with the respective serial port SHOWSET commands (SHO,
SHO L, SHO G, SHO R, SHO T, and SHO P). See SHO Command (Show/
View Settings) on page 10.25.
Table 9.1 Serial Port SET Commands
Command
Settings
Type
Description
Settings
Sheets
a
a
Located at the end of this section.
SET m Relay Distance, overcurrent and voltage elements,
reclosing relay, timers, etc., for settings group m
(
m = 1, 2, 3, 4, 5, 6).
1–15
SET L m Logic SEL
OGIC
®
control equations
for settings group m (m = 1, 2, 3, 4, 5, 6).
16–21
SET G Global Battery and breaker monitors, optoisolated
input debounce timers, synchrophasors, etc.
22–24
SET R SER Sequential Events Recorder trigger conditions. 25
SET T Text Front-panel default display and local control text. 26–29
SET P m Port Serial port settings for
Serial Port m (m = 1, 2, 3, or F).
30–32
